Significant changes have been implemented in the UML metamodel for improved performance. Profiling Changes in the UML 2.5.1 Metamodel The active validation of the model now takes less than a second (0.8s after 5M project load and 0.5s after diagram load).Ī chart comparing the active validation speed after the project and diagram load in 19.0 SPx projects containing 5M elements (including used projects). Creating the first numbered element, copying/pasting numbered elements, renumbering elements recursively, and updating the last element ID is now 30-840 times faster.Ī chart comparing the Numbering operations speed in 19.0 SPx projects containing 10M elements (including used projects).Įlement Selection. Now you can search and select the needed elements (e.g., in the Select Element and Quick Find dialogs as well as drop-down lists) approximately 40-50 times faster.Ī chart comparing the element selection speed in 19.0 SPx projects containing 5M elements (including used projects). The search speed in all texts has increased by 70-150% compared to 19.0 SP4.Ī chart comparing the Find operation speed in 19.0 SPx projects containing 1M, 2M, and 5M elements (including used projects).
Copy/Paste. Now you can copy and paste data 2-4 times faster depending on the specific scenario.Ī chart comparing the copy&paste operation time in various scenarios.The import of 61k elements takes only 2 minutes (see the chart below).Ī chart comparing data import from Excel and CSV files using the Excel/CSV Sync and Excel/CSV Import dialogs. Also, the d ata import using the new Excel/CSV Import dialog is even better in comparison to Excel/CSV Sync feature. The data import time using the table sync feature is significantly faster compared with the previous version (19.0 SP4). The import performance of data from an Excel or CSV file into the modeling tool adds a great experience while managing a large scope of data. Learn more about partial loading in tables > Increased Excel and CSV files Import Speed Additionally, fast scrolling has improved it is now considerably smoother.Ī chart comparing the opening time of Requirement Table having 7 standard columns with a different number of requirements. There is no longer a need to wait until data is calculated in the entire table. For further information, please check the latest documentation.Ĭlient-side Performance Improvements Partial Data Loading in TablesĮxperience enhanced table loading and scrolling performance! Thanks to the newly-introduced Load Partially mode, data is now loaded in only visible rows. Don't forget to give us your feedback on LinkedIn, Twitter, or Facebook. Last but not least, project merge has been extended to give users the option to show only the changes in directly modified diagrams, hide Target and Equivalent Changes by default, and choose a specific ancestor calculation algorithm depending on merge scenario and expected outcome.ĭownload the newest MagicDraw version at or contact your sales representative. Additionally, the Excel/CSV file import functionality has been reviewed and refreshed, and numerous improvements to Excel/CSV synchronization functionality in tables have been added.
MAGICDRAW SYSML DOWNLOAD FULL
Version 2021x adds the ability to use layers in diagrams, automatically create legends, present diagrams or predefined sequences of diagrams in full screen to stakeholders, create compositions and aggregations in matrices, and use predefined element type filters when searching for the necessary model elements. This release brings significant performance and scalability upgrades in key product areas: Merge, Teamwork Cloud project load, Teamwork Cloud project saving, table loading, Excel and CSV files import, and such common modeling tool operations as Copy/Paste, Find, Numbering, Element Selection, and Validation.
